Product Details:
|
| Ex Mark: | Ex Db Eb IIC T6 Gb/Ex Tb IIIC T80℃ Db | Corrosion Resistant: | WF2 |
|---|---|---|---|
| Frequency: | 50/60Hz | Beam Angle: | 120-140℃ |
| Power Factor: | 0.95 | Lamp Luminous Efficiency: | 100lm/w |
| Colour Rendering [CRI]: | 70 (±2) | Cable Entry: | G 3/4” |
| Colour Temperature [K]: | 6000-6500 | ||
| Highlight: | WF2 Explosion Proof Fluorescent Light,Safety Class Explosion Proof Fluorescent Light,Corrosion Resistant Explosion Proof Fluorescent Light |
||
Features:
5.Multi choice of beam angle for 45° 90°120°
Applications
| Typical applications include: |
| Oil and gas industries |
| Chemical, petrochemical |
| Pharmaceutical industries |
| Pulp and Paper |
| Waste and sewage treatment |
| Power Generation |
| Other high humidity, high dust, high temperature, vapor locations |
| Housing: | Die-casting aluminum |
| Exterior: | Stainless steel |
| Globe: | Tempered glass |
| Gasket: | Silicon rubber |
| Certifications | ATEX CNEX CE RoHS ISO9001 |
| Ex Marking | Ex nR eb mb IIC T5 Gc/ Ex tb IIIC T80℃ Dc |
| For use in | Zone 1, 2 & Zone 21, 22 |
| Rated voltage | 100-240VAC, 50-60Hz |
| Power factor | >0.95 |
| THD | <20% |
| Degree of protection | IP66 |
| Conduit Entries | G 3/4" |
| Terminal | ≤2.5 mm² |
| Mounting Styles | Ceiling; Wall Bracket; Pendant |
| Power consumption [W] | 20-40 | 40-60 | 60-80 |
| Colour rendering [CRI] | 70 (±2) | ||
| Colour temperature [K] | 6000-6500 | ||
| Weight[kg] | 4.5 | 6.5 | 8 |
| Luminaire efficiency [Lm/W] | 115-130 | ||
| Beam angle | 120° | ||
Installation Instructions:
Before installation, check voltage, power and other parameters carefully and
make installation preparations arrordingly to layout circuit.
1. organize firstly supporting spare parts and accessories
2. do shut off power before installation
3. the loading capacity of the ceilingfixed item where the lamp is installed should be the same as the lamp weight
4. do power-on test to make sure the lamp can be lighted
5. make sure the lamp is installed firmly, turn on the light finally
Company information:
Crown Extra Lighting Co., Ltd. is a comprehensive enterprise integrating R&D, production, sales and service.
The company is located in Changzhou, known as the "Dragon City" in the Yangtze River
Delta of China. The company is committed to becoming a provider of green, environmentally friendly,
energy-saving, and leading industrial lighting solutions, providing high-quality lighting products for
petroleum, petrochemical, electric power, metallurgy, railways, aerospace, military, public security,
fire fighting, ships, roads, pharmaceuticals, etc. And professional technical service programs.
FAQ:
Q1. Can I have a sample order for explosion-proof led light?
A: Yes, we welcome sample order to test and check quality. Mixed samples are acceptable.
Q2: What kind of payments do you accept?
A:T/T, L/C, Western Union,, MoneyGram, etc..
Q3:What is you main products?
A: Explosion-proof LED light ,explosion-proof box,explosion proof fittings, etc.
Q4: Do you offer guarantee for the products?
A: Yes, we offer 3-5 years warranty to our products.
Q5: What's the MOQ?
A:MOQ is 1 set.
