Warehouse Industrial Lighting Ufo Explosion Proof Led High Bay 135lm/w 100W 150W 200W

Warehouse Industrial Lighting Ufo Explosion Proof Led High Bay 135lm/w 100W 150W 200W
Warehouse Industrial Lighting Ufo Explosion Proof Led High Bay 135lm/w 100W 150W 200W Warehouse Industrial Lighting Ufo Explosion Proof Led High Bay 135lm/w 100W 150W 200W Warehouse Industrial Lighting Ufo Explosion Proof Led High Bay 135lm/w 100W 150W 200W

Large Image :  Warehouse Industrial Lighting Ufo Explosion Proof Led High Bay 135lm/w 100W 150W 200W

Product Details:
Place of Origin: China, Jiangsu
Brand Name: Crown Extra
Certification: CE, ROHS, ISO, ATEX
Model Number: GYD620
Payment & Shipping Terms:
Minimum Order Quantity: 1SET
Price: USD57-158/set
Packaging Details: CARTON、WOODEN BOX、PALLET
Delivery Time: 5-7 working days
Payment Terms: T/T, Western Union
Supply Ability: 50000SET/Mounth

Warehouse Industrial Lighting Ufo Explosion Proof Led High Bay 135lm/w 100W 150W 200W

Description
Beam Angle: 60° 90° 120° Light Source: LED, CREE
Lamp Luminous Efficiency: 135lm/w Color Temperature: 5500K-6500K
CRI: Ra:≥80 Input Voltage: 90-305VAC/50~60HZ Or 24V DC
USED ZONE: Zone 2 And 21, 22 Lifespan: 50,000hrs
Highlight:

100W Ufo Led high bay

,

200W Ufo Led high bay

,

135lm/w Ufo Led high bay

Warehouse Industrial Lighting Ufo Led high bay 135lm/w 100W 150W 200W explosion proof High Bay Light

Product Description:

The lifespan of these high bay lights is an impressive 50,000 hours, providing long-lasting and efficient lighting for your workplace. The light source is CREE LED, which is known for its high brightness and energy efficiency. This makes the Explosion Proof LED High Bay Lights an ideal choice for businesses looking to reduce energy costs and improve their carbon footprint.

With a WF degree of WF2, these explosion proof high bay lights are suitable for use in areas where there is a risk of flammable gases or dust. The color temperature of the lights is 5500K-6500K, which provides a bright and clear light that is perfect for industrial settings.

The explosion proof grade of these high bay lights is Ex Db Eb IIC T6 Gb, which means that they are capable of withstanding an explosion without igniting surrounding flammable gases or dust. The Ex Tb IIIC IP66 T80° rating ensures that the lights are protected against water and dust ingress, making them suitable for use in harsh environments.

Overall, the Explosion Proof LED High Bay Lights are an excellent choice for businesses looking for high bay explosion proof lighting that is reliable, energy efficient, and long-lasting.



Features:

  • Product Name: Explosion Proof LED High Bay Lights
  • Working Temperature: -20℃~+60℃
  • CRI: >80, >70
  • WF degree: WF2
  • Light Source: LED, CREE
  • USED ZONE: Zone 2 And 21, 22
  • Features: ATEX approved LED lighting, explosion proof high bay lighting, explosion proof high bay fixture


Technical Parameters:

Warehouse Industrial Lighting Ufo Explosion Proof Led High Bay 135lm/w 100W 150W 200W 0

Technical Parameter Value
For use in Zone 1, 2 & Zone 21, 22
Rated voltage 100-277VAC, 50-60Hz
Power factor >0.95
THD <20%
Power consumption [W] 50-100w, 120-150w,150-200w,240w
Colour rendering [CRI] 70 (±2)
Colour temperature [K] 6000-6500
Luminaire efficiency[Lm/W] 125-130
Beam angle 120° (45°, 90° is optional)
Degree of protection IP66
Cable entry G 3/4”
Weight [kg] 5.25,6.85,8.6,10.25
Terminal ≤2.5 mm²
Mounting Styles Ceiling; Wall Bracket; Pendant



Warehouse Industrial Lighting Ufo Explosion Proof Led High Bay 135lm/w 100W 150W 200W 1

Applications:

With an input voltage of 90-305VAC/50~60HZ or 24V DC, these explosion proof high bay lights have a color temperature of 5500K-6500K. They have a WF degree of WF2 and a CRI of >80, >70.

The Crown Extra GYD620 explosion proof LED high bay lights can be used in a variety of occasions and scenarios such as:

  • Oil and gas refineries
  • Chemical plants
  • Mining operations
  • Power plants
  • Pharmaceutical factories
  • Food processing facilities
  • Warehouses
  • Workshops

These explosion proof high bay lights are available for a minimum order quantity of 1 set and have a price range of $50-$200. They are packaged in cartons and pallets and have a delivery time of 7 working days. Payment terms include T/T, Western Union, and L/C. The Crown Extra GYD620 explosion proof LED high bay lights have a supply ability of 2000 pieces per month.



Customization:



FAQ:

A: The brand name is Crown Extra.

Q: What is the model number of the Explosion Proof LED High Bay Lights?

A: The model number is GYD620.

Q: Where is the Explosion Proof LED High Bay Lights manufactured?

A: The LED lights are manufactured in China, specifically in Jiangsu.

Q: What certifications does the Explosion Proof LED High Bay Lights have?

A: The LED lights have CE, ROHS, ISO, and ATEX certifications.

Q: What is the minimum order quantity for the Explosion Proof LED High Bay Lights?

A: The minimum order quantity is 1 set.

Q: What is the price range for the Explosion Proof LED High Bay Lights?

A: The price range is between $50-$200.

Q: How are the Explosion Proof LED High Bay Lights packaged?

A: The LED lights are packed in cartons and on pallets.

Q: What is the delivery time for the Explosion Proof LED High Bay Lights?

A: The delivery time is 7 working days.

Q: What are the payment terms for the Explosion Proof LED High Bay Lights?

A: The payment terms include T/T, Western Union, and L/C.

Q: What is the supply ability for the Explosion Proof LED High Bay Lights?

A: The supply ability is 2000 pieces per month.
